An introduction to the GraphQL puzzle
- Date:
- Author:
- Śūnya
- Reading time:
- 5 min read
The intention of this series of articles is to take a high level overview the puzzle pieces of the GraphQL architecture; introducing each piece and where it fits in the puzzle and how the pieces work together. This seems necessary because GraphQL is not a single thing or a single piece of technology, rather it spans the full stack and can be implemented in many different ways
What is GraphQL
Technically, GraphQL is a specification for a “query Language” designed to query (and mutate) “graphs” of data… aaand unpacking that…
A “specification” is a description of something (like the WC3 specification for HTML or CSS), as distinct from the implementations of that thing (like the various browser implementations of HTML/CSS).
A “graph” of data is fundamentally a set of data that has a defined relationship; graphs are a Computer Science term for a data structure made up of “nodes” (or “points” or “vertices”) and the connections between them, “links” (or “edges” or “lines” or “arrows”). This means that the data connections (relationships) are part of the data and not added on through things like foreign keys, etc.
So we can say that GraphQL is a language specification for querying and mutating data with and from their relationships.
In practice however, it is a bit more than that. On the one hand it is a query language. On the other it is a language for describing those graphs (GraphQL schema). And on the third hand, it is a architectural pattern to allow the schema to remain absolutely agnostic to the origin and shape of the original data (the resolver pattern).
These 3 things make up the “pieces” of a GraphQL system regardless of the rest of the system. This series is about an overview of each and how it works with the others. It will be as example laden as possible to illustrate the terms and ideas.
First up Schema because it sits in the middle of the architecture and underpins the other parts.
Schema
The Schema in a GraphQL API is designed to be an “expressive shared language” between all parts of your stack and as such, the GraphQL Schema language has been specifically designed to describe data - specifically, graphs of data. It has a really small but flexible syntax, with only a few very simple data types - called Scalar types.
- Int: A signed 32‐bit integer, e.g.
10,1000,26, etc - Float: A signed double-precision floating-point value, e.g.
3.14159 - String: A UTF‐8 character sequence, e.g.
hello,world - Boolean: true or false.
- ID: The ID scalar type represents a unique identifier. It is similar to an string, but intended to be unique.
and 2 main structural types:
- list and
- object
Combined, these allow us to describe most structures of data. For the few situations where these are insufficient (e.g. Dates), it is usually possible to declare custom data types. There are some other scalars and structural types (some of which we’ll cover below) but these ones do the bulk of the work.
To see what this looks like, let’s make a Person in GraphQL schema.
type Person {
id: ID!
name: String
age: Int
hobbies: [String]
}Firstly we declare a new type and name it Person. The most fundamental components of a schema are object types, which describe a number of related fields that you can fetch from your API - this is a small graph. Our Person is an object with a name, age and some hobbies… The name is a string, as you might expect, and age is a number (Int) as you might expect. For hobbies, we wanted to allow our Person to be passionate about more than one thing, so we allow them to have more than one hobby String by using the list structure.
In Schema language everything is optional unless we specifically say it is required and so far we have not required the people of our system to have names, hobbies or even an age, but because we want each Person that we create to be uniquely identifiable, we use the built in ID type to describe a unique identifier, and we indicate that this is required with a !.
So you can see that we can achieve a lot with relatively simple set of “scalar” types. So far this is not much different from a Person table in a database… but as the people in our system tend to be very outgoing, they make a lot of friends from different neighbourhoods.
type Person {
id: ID!
name: String
age: Int
hobbies: [String]
friends: [Person]
}Now we can see the power of graphs, because that list of Person types doesn’t just reference a Person.id as a foreign key, but a “link” to the actual Person data nodes.
Even more, if we add an Address type, we can see how we can quickly describe quite complex data and their relationships:
type Person {
id: ID!
name: String
age: Int
hobbies: [String]
friends: [Person]
address: [Address]
}
<!-- Declare a completely custom scalar (that our system must implement) -->
scalar AddressUnit
type Address {
id: ID!
unitNameOrNumber: AddressUnit
streetName: String
city: String
neighbourhood: Neighbourhood!
location: LatLong!
country: Country
}
type Neighbourhood {
id: ID!
name: String
boundary: GeoShape!
}
type GeoShape {
id: ID!
points: [LatLong!]!
}
type LatLong {
id: ID!
lat: Float!
long: Float!
}
enum Country {
NEVERLAND
OZ
ETERNIA
}There are a few interesting things to note in these new descriptions of data relationships. We have a described some complex relationships and also introduced a couple of new types.
The first new type is the Address type’s unitNameOrNumber field; the AddressUnit is a new scalar that can be either a String or an Int. GraphQL doesn’t currently support scalar union types, but with custom scalars, essentially it is up to the implementation how this is validated.
Another way to allow different values for a field, but limit it to a limited set of values is to use the enum (enumeration) type, like the Country enum type. Enums allow you to:
- Validate any arguments of this type
- Communicate that a field will always be one of these values and nothing else
The final thing of interest to note is the type declaration for the points field in the GeoShape type, [LatLong!]!. The ! tells us that the value is required or cannot be null, but here we are saying that the field must always have a list, which can be empty but none of the values in the list can be null.
That is pretty much it for describing data shapes and relationships; there is one more utility that can help describe data shape expectations - the interface. Interfaces are ubiquitous in strongly typed languages, but in GraphQL Schema language, they might be a little confusing.
Implementation details
Interfaces are a way of describing the shape of something without describing the thing itself - like describing a car by saying “it has 4 wheels, an engine, no more than 6 seats and some windows’, we can make look at a Tesla, and a Ferrari and agree that both fit that description even thought we haven’t described the actual, “concrete” cars themselves.
Interfaces are called “abstract” because they are not used directly, rather we use them to make sure that “concrete” types fit the description, or interface described. When this happens, we say that the concrete type “implements” the interface. As an example, let’s say that we have a number of different peoples of our lands. Let’s convert our Person type into an interface and make some more specific, concrete people types.
interface Person {
id: ID!
age: Int
name: String
hobbies: [String]
friends: [Person]
address: [Address]
}
type Human implements Person {
eyeColour: String
friends: [Person]
id: ID!
age: Int
name: String
hobbies: [String]
address: [Address]
}
type Tree implements Person {
evergreen: Boolean
id: ID!
age: Int
name: String
hobbies: [String]
friends: [Person]
address: [Address]
}
type Jellyfish implements Person {
symbiotes: [Person!]
id: ID!
age: Int
name: String
hobbies: [String]
friends: [Person]
address: [Address]
}With the above code, we can ensure all the fields in the Person interface are in our “concrete” type’s declaration by telling the Schema that the type implements Person; anything that we add to the concrete type’s declaration is additional to the fields in Person - e.g. the Human type also has a eyeColour field.
There are other benefits to using interfaces that we’ll cover in Part 2, GraphQL, Say what? Queries and Mutations.
Describing data summary
The Schema language gives us a powerful way to both describe data and to describe the relationships in the data. This was an overview of the most commonly useful parts of the language, but it was by no means exhaustive.
As an interesting exercise to embed some of these concepts, you could try making some types for the people and characters of the Lord of the Rings universe, or the Marvel
